Specifications
Power Output (continuous)
@ 8 ohms – 350 Watts RMS
@ 4 ohms – 560 Watts RMS
@ 2 ohms – 705 Watts RMS
Output Current
90 Amps peak
Frequency Response
±0.1 dB, DC-150 KHz
±1 dB, DC-1 MHz
±3 dB, DC-1.8 MHz
Distortion
Static: Less than 0.015% from DC to 100 KHz. Typically 0.009% @ 350 Watts RMS / 8 ohms
Dynamic: 8 Tone Cluster Test 20 KHz @ 500 Hz separation; 0.01% 8 ohms; 0.015% / 4 ohms
Speed
Rise Time: Less than 225 nanoseconds
Settling: 1.5 microseconds to -40dB
Slew Rate: 650 volts/microsecond
Noise
Signal to Noise: 98dB unweighted, 108dB ASA A
Crosstalk: 102dB @ full power 8 ohms
Input
Impedance: 10K
Sensitivity: 1.5V nominal output
Power Supply
Line Voltage: 100 volts, 120 volts, 240 volts (internal wiring/factory)
AC Voltage Range: +/- 10%
Maximum Consumption: 2000 watts
Quiescent Consumption: 115 watts
Operating Temp. : 0° to 50° Celsius range; 32° to 122° Farenheit
Protection Features
DC Protection Servo: 0.5V range
Current Limit Onset: 90 amps
Thermal Threshold: Protects at 85° Celsius, 185° Farenheit
AC Main Fuses: 2 @ 5A 3 AG slo-blo, for 100 – 120 VAC 2 @ 2-1/2A 3AG slo-blo, for 220-240 VAC
Mechanical Specifications
Dimensions: 20″ (50.8 cm), W x 7 1/4″ (18.4cm) H x 19.6″ (49.9 cm) D
Weight: 72 lbs (34.0) kg net
