Type |
Direct Power System |
Frequency Response |
15 – 30,000Hz |
Channel Separation |
30dB (1kHz) |
Output Channel Balance |
0.5dB (1kHz) |
Output Voltage |
0.2mV (1kHz, 5 cm/sec.) |
Vertical Tracking Angle |
21˚ |
Vertical Tracking Force Range |
Due to the unique construction of the AT-ART1000, each individual cartridge is supplied with its own tracking force measurement to allow optimum setting, which is between a range of 2.0 to 2.5g |
Stylus Construction |
Special Line Contact |
Cantilever |
0.26mm (0.01”) diameter solid boron |
Coil Impedance |
3Ω (1kHz) |
Static Compliance |
30 x 10-6 cm/dyne |
Dynamic Compliance |
12 x 10-6 cm/dyne (100Hz) |
Recommended Load Impedance |
30Ω |
Weight |
11.0g |
Accessories Included |
Non-magnetic screw driver, 2 x Washer, Protector, 2 x Nut, Cartridge installation screws (2 x 12mm, 2 x 18mm), Brush, PCOCC Lead wire set |
