| Type |
VM Type |
| Mounting |
1/2” centres |
| Frequency Response |
20 – 20,000Hz |
| Output Voltage |
3.0mV (1kHz, 5cm/sec.) |
| Vertical Tracking Angle |
23˚ |
| Vertical Tracking Force Range |
4.5 – 5.5g (5.0g standard) |
| Stylus Shape |
Conical Bonded (3mil) |
| Stylus Size |
3.0 mil |
| Stylus Construction |
Bonded Round Shank |
| Cantilever |
Aluminium Pipe |
| Coil Impedance |
1,400Ω (1kHz) |
| Static Compliance |
15 x 10-6 cm/dyne |
| Dynamic Compliance |
2.0 x 10-6 cm/dyne (100Hz) |
| Recommended Load Impedance |
47,000Ω |
| Recommended Load Capacitance |
100 – 200pF |
| Weight |
6.4g |
| Dimensions |
17.3 (H) x 17.0 (W) x 28.2 (L) mm |
| Replacement Stylus |
VMN70SP |
| Accessories Included |
Cartridge installation screws 5mm ×2 and 10mm ×2, Washer ×2, Hexagon nut ×2 |
